MXR M242 Iso-Brick Pro 10-output Isolated Pedal Power Supply

The MXR M242 Iso-Brick Pro 10-output Isolated Pedal Power Supply is a high-capacity, ultra-quiet solution designed for modern pedalboards that demand reliable, noise-free power. With fully isolated outputs and multiple voltage options, it is built to handle everything from simple analog stompboxes to complex digital multi-effects systems without compromise.

Designed for flexibility and touring durability, the Iso-Brick Pro features a low-profile metal chassis that fits neatly under most pedalboards, along with included mounting hardware for secure installation. Its wide range of outputs—including switchable voltage options and high-current dedicated outputs—makes it a complete power hub for professional rigs. Available from Sky Music Australia, it’s built to keep your sound clean and consistent night after night.

Features

• 10 fully isolated outputs for ultra-quiet, noise-free operation
• 6 fixed 9V outputs for standard pedal powering needs
• 2 switchable outputs (9V / 12V / 18V) for flexible voltage matching
• Dedicated 9V DC 1.5A high-current output for multi-effects units
• Dedicated 18V DC 2A output for power supply linking
• Eliminates ground loop hum and unwanted noise
• Low-profile, lightweight metal chassis designed for pedalboard mounting
• Includes mounting brackets and screws for easy installation

Specs

• Product Type: Isolated Pedalboard Power Supply
• Model: MXR M242 Iso-Brick Pro
• Total Outputs: 10 Isolated Outputs
• Output Configuration: 4 x 9V 300mA, 2 x 9V 500mA, 2 x 9V / 12V / 18V 500mA, 1 x 9V 1.5A, 1 x 18V 2A
• Input Power: 120V AC (IEC connection)
• Isolation: Fully isolated outputs
• Construction: Rugged metal housing
• Mounting: Includes brackets and screws
• Dimensions: 9.25" W x 3.43" D x 1.43" H
• Weight: 1.9 lbs
